Beautifully crafted with the modern professional in mind, the highly secure and manageable HP EliteBook 830 3JW87EA offers powerful collaboration tools, so you can be as productive as ever, on the go or at the office.
HP EliteBook 830 3JW87EA Features
Brilliant new design
This stunning ultra-slim, aluminum laptop goes anywhere, and looks great doing it featuring a narrow border IPS display.
Built on a secure foundation
Protect your PC against the evolving malware threats of the future, with self-healing, hardware-enforced, and manageable security solutions from HP. From the BIOS to the browser HP Sure Start Gen and HP Sure Click help secure your PC.
Crystal-clear collaboration
Calls sound crisp and clear with advanced collaboration features like HP Noise Cancellation. Loud top-firing speakers produce rich sound. The world-facing third microphone and collaboration keys help make PC calls productive.
A modern docking solution
Quickly transition to desktop productivity with a single USB-C™-cable. The optional HP Thunderbolt Dock G2 delivers enterprise manageability and an optional audio module. Traditional side docking is also supported to work with your existing solution.
Let nothing stand in your way
Power through your day with Windows 10 Pro and the powerful security, collaboration and connectivity features from HP.
High performance, high portability.
Help speed up demanding business applications with an optional 8th Gen quad-core Intel® Core™ processor.
Preserve your privacy
Never wonder if someone is watching you with the added peace-of-mind that comes from the integrated HP Privacy Camera, with a physical shutter to protect from malicious surveillance.
Firmware level protection
Protect your PC with the hardware-enforced self-healing protection of HP Sure Start Gen4 that automatically recovers the BIOS.
Protect critical security processes
Keep your critical applications and processes running even if malware tries to shut them down with self-healing protection.
Keep visual hackers in the dark
Instantly protect against visual hacking with the optional HP Sure View Gen2 integrated privacy screen. At the touch of a button your screen appears unreadable to those around you while you see your content clearly.
Browse confidently
Help protect your PC from websites and in-browser .pdf files infected with malware, ransomware, or viruses with HP Sure Click.
Protect identities with HP Multi-Factor Authenticate Gen2
Fortify your security with up to three authentication factors including fingerprints and facial recognition.
Stay Connected
Stay connected with support for the latest global 4G LTE wireless broadband technology.
Windows 10 or other operating systems available
|
Specification
|
Description
|
|
Preinstalled
|
Windows 10 Pro 641
Windows 10 Home 641
FreeDOS 1.2
|
NOTE:
1Not all features are available in all editions or versions of Windows. Systems might require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 automatic updates are always enabled. ISP fees might apply and additional requirements might apply over time for updates.
In accordance with Microsoft support policy, this product does not support Windows 8 or Windows 7. HP does not support the Windows 8 or Windows 7 operating system on products configured with Intel and AMD 7th generation or later processors, or provide any Windows 8 or Windows 7 drivers.
Processors
|
Specification
|
Description
|
|
Intel Core i5-7200U
|
2.5 GHz base frequency, up to 3.1 GHz with Intel Turbo Boost Technology
3 MB cache and 2 cores
Intel HD Graphics 620
|
|
Intel Core i5-7300U
|
2.6 GHz base frequency, up to 3.5 GHz with Intel Turbo Boost Technology
3 MB cache and 2 cores
Intel HD Graphics 620
|
|
Intel Core i5-8250U
|
1.6 GHz base frequency, up to 3.4 GHz with Intel Turbo Boost Technology
6 MB cache and 4 cores
Intel UHD Graphics 620
|
|
Intel Core i5-8350U
|
1.7 GHz base frequency, up to 3.6 GHz with Intel Turbo Boost Technology
6 MB cache and 4 cores
Intel UHD Graphics 620
|
|
Intel Core i7-8550U
|
1.8 GHz base frequency, up to 4.0 GHz with Intel Turbo Boost Technology
8 MB cache and 4 cores
Intel UHD Graphics 620
|
|
Intel Core i7-8650U
|
1.9 GHz base frequency, up to 3.9 GHz with Intel Turbo Boost Technology
8 MB cache and 4 cores
Intel UHD Graphics 620
|
|
Chipset
|
Integrated with processor
|
NOTE:
Multicore is designed to improve performance of certain software products. Not all customers or software applications necessarily benefit from use of this technology. Performance and clock frequency vary depending on application workload and hardware and software configurations. Intel numbering is not a measurement of higher performance.
Processor speed denotes maximum performance mode; processors run at lower speeds in battery optimization mode.
Graphics
|
Specification
|
Description
|
|
Integrated
|
Intel HD Graphics 620
Intel UHD Graphics 620
|
|
Supported
|
Supports HD decode, DX12, and HDMI 1.4b
|
NOTE:
High-definition (HD) content is required to view high definition images.
Display
|
Specification
|
Description
|
|
Non-touch (sold separately or as an optional feature)
|
33.78 cm (13.3 in) diagonal FHD IPS anti-glare LED-backlit, 220 cd/m2, 45% sRGB (1920 x 1080)
33.78 cm (13.3 in) diagonal FHD IPS anti-glare LED-backlit, 220 cd/m2, 45% sRGB with HD camera (1920 x 1080)
33.78 cm (13.3 in) diagonal FHD IPS anti-glare LED-backlit, 220 cd/m2, 45% sRGB with HD IR camera (1920 x 1080)
33.78 cm (13.3 in) diagonal FHD IPS anti-glare LED-backlit, 220 cd/m2, 45% sRGB for WWAN (1920 x 1080)
33.78 cm (13.3 in) diagonal FHD IPS anti-glare LED-backlit, 220 cd/m2, 45% sRGB with HD camera for WWAN (1920 x 1080)
33.78 cm (13.3 in) diagonal FHD IPS anti-glare LED-backlit, 220 cd/m2, 45% sRGB with HD IR webcam for WWAN (1920 x 1080)
33.78 cm (13.3 in) diagonal FHD IPS anti-glare LED-backlit, 400 cd/m2, 72% sRGB with ambient light sensor and HD IR webcam (1920 x 1080)
33.78 cm (13.3 in) diagonal FHD IPS anti-glare LED-backlit, 400 cd/m2, 72% sRGB with ambient light sensor and HD IR webcam for WWAN (1920 x 1080)
|
|
Touch (sold separately or as an optional feature)
|
33.78 cm (13.3 in) diagonal FHD IPS LED-backlit touch screen with Corning Gorilla Glass 3, 220 cd/m2, 45% sRGB with HD IR camera (1920 x 1080)
33.78 cm (13.3 in) diagonal FHD IPS LED-backlit touch screen with Corning Gorilla Glass 3, 220 cd/m2, 45% sRGB with HD IR webcam for WWAN (1920 x 1080)
|
|
HDMI 1.4b
|
Supports resolution up to 4k at 60 Hz
|
|
Displays supported
|
Supports 2 independent displays when docked on the HP Ultraslim Dock
|
NOTE:
High-definition (HD) content is required to view high definition images.
Resolutions are dependent upon monitor capability, and resolution and color depth settings.
Memory
|
Specification
|
Description
|
|
Standard
|
DDDR4-PC4 SODIMMS
(2) SODIMM slots (both slots are customer accessible/upgradable)
Runs at 2133 MT/s for Intel 7th generation processors
Runs at 2400 MT/s for Intel 8th generation processors
|
|
Configurations
|
32 GB DDR4-2400 SDRAM (16 GB x 2)
16 GB DDR4-2400 SDRAM (16 GB x 1)
16 GB DDR4-2400 SDRAM (8 GB x 2)
8 GB DDR4-2400 SDRAM (8 GB x 1)
8 GB DDR4-2400 SDRAM (4 GB x 2)
4 GB DDR4-2400 SDRAM (4 GB x 1)
|
|
Maximum
|
32 GB
|
NOTE:
Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If memory speeds are mixed, the system performs at the lower memory speed.
Storage/drives
|
Specification
|
Description
|
|
Primary M.2 Solid State Drive storage
|
128 GB SATA-3 TLC SSD
256 GB PCIe NVMe Value TLC SSD
256 GB PCIe Gen 3x4 NVMe TLC SSD
256 GB SATA-3 TLC Opal 2 SSD
360 GB PCIe Gen 3x4 NVMe TLC SSD (Intel)
512 GB PCIe Gen 3x4 NVMe TLC SSD
512 GB PCIe Gen 3x4 NVMe TLC Opal 2 SSD
512 GB SATA-3 TLC FIPS-140-2 SSD
1 TB PCIe Gen 3x4 NVMe TLC SSD
|
NOTE:
1For solid state drives or hard drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows 10) is reserved for system recovery software.
Ports/slots
|
Specification
|
Description
|
|
Ports
|
(1) Thunderbolt (USB Type-C connector)
(2) USB 3.1 Gen 1 (1 charging)
(1) HDMI 1.4b port (cable sold separately)
(1) RJ-45/Ethernet port
(1) Docking connector
(1) Headphone/microphone combo jack
(1) AC power port
(1) VGA port
|
|
Slot
|
(1) SIM card slot
(1) Smart card reader
NOTE:
Sold separately or as an optional feature.
|
Audio/multimedia
|
Specification
|
Description
|
|
Audio
|
Audio by Bang & Olufsen
(3) Integrated Multi-array microphone
(2) Integrated Stereo Speakers (74 dB)
|
|
Camera
|
HD camera
HD IR camera
NOTE:
HD content required to view HD images. Internet access required.
|
Keyboards/pointing devices/function keys
|
Specification
|
Description
|
|
HP Premium keyboard
|
Spill-resistant with drain (thin layer of Mylar film under the keyboard)
Backlit (optional)
|
|
Pointing devices
|
Clickpad with multi-touch gestures enabled (taps enabled as default)
Microsoft Precision Touchpad default gestures supported
|
|
Function keys
|
Function keys
ESC – System information
F1 – Display switching
F2 – Blank
F3 – Brightness down
F4 – Brightness up
F5 – Speaker mute
F6 – Volume down
F7 – Volume up
F8 – Microphone mute
F9 – Backlight toggle (for backlit keyboard) or blank
F10 – Blank
F11 – Wifi toggle
F12 – Sleep
Share/present
Call answer
Call end
Hidden fuctions
Fn+R – Break
Fn+S – Sys Rq
Fn+C – Scroll Lock
|
Networking/communication
|
Specification
|
Description
|
|
Wireless LAN (WLAN)
|
Intel Dual Band Wireless-AC 8265 802.11a/b/g/n/ac (2x2) Wi-Fi and Bluetooth 4.2 Combo, vPro
Intel Dual Band Wireless-AC 8265 802.11a/b/g/n/ac (2x2) Wi-Fi and Bluetooth 4.2 Combo, non-vPro
Realtek RTL8822BE 802.11ac (2x2) Wi-Fi and Bluetooth 4.2 Combo, non-vPro
NOTE:
Wireless access point and Internet service is required and is not included. Availability of public wireless access points limited. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it might affect the ability of the notebook to communicate with other 802.11ac WLAN devices.
|
|
WWAN
|
HP lt4132 LTE/HSPA+ 4G Mobile Broadband
Intel XMM 7360 LTE-Advanced
NOTE:
WWAN use requires separately purchased service contract. Check with service provider for coverage and availability. Connection speeds varies due to location, environment, network conditions, and other factors. 4G LTE not available on all products, and in all countries/regions.
|
|
Near Field Communication (NFC)
|
NXP NPC300 Near Field Communication module
|
|
Ethernet
|
Intel I219-LM 10/100/1000 GbE, vPro
Intel I219-V 10/100/1000 GbE, non-vPro
NOTE:
The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required.
|
Software/security
|
Specification
|
Description
|
|
BIOS
|
HP BIOSphere Gen4 (requires Intel 8th generation processors)
HP Sure Start Gen4 (requires Intel 8th generation processors)
HP DriveLock/HP Automatic DriveLock
BIOS Update via Network
Master Boot Record Security
Power On Authentication
Secure Erase (methods outlined in the National Institute of Standards and Technology Special Publication 800-88)
Absolute Persistence Module1
Pre-boot Authentication
HP Wireless Wakeup
|
|
Communication/connectivity
|
HP Native Miracast support
HP LAN-WLAN Protection
|
|
HP Value add software
|
HP Velocity v1.5
HP ePrint Driver with JetAdvantage2
HP Hotkey Support - CMIT
HP Recovery Manager
HP Jumpstart
HP Support Assistant (requires Windows and internet access)
HP Noise Cancellation software
HP Performance Advisor
Ivanti Management Suite (subscription required)
|
|
Microsoft products
|
Buy Office
|
|
Manageability
|
HP Driver packs (available for download)
HP SoftPaq Download Manager (SDM)
HP System Software Manager (SSM) (available for download)
HP BIOS Configuration Utility (BCU) (available for download)
HP Client Catalog (available for download)
HP Management Integration Kit for Microsoft SCCM (available for download)
HP Image Assistant
NOTE:
For more information about manageability software, go to the HP Client Management Solutions webpage.
|
|
Client Security software
|
Microsoft Defender (opt in and internet connection required for updates)
HP Client Security Suite Gen4 (requires Windows)
HP Security Manager (including Credential Manager and HP Password Manager, and HP Spare Key)
HP Fingerprint Sensor (sold separately or as an optional feature)
Power On Authentication
HP Device Access Manager
HP Sure Click (supports Microsoft Internet Explorer and Chromium)
HP Sure Run (requires 8th generation processors)
HP Sure Recover (requires 8th generation processors)
|
|
Security
|
For Windows 10, Trusted Platform Module (TPM) 2.0 (Infineon SLB9670)
Common Criteria EAL4+ Certified
HP Fingerprint Reader
NOTE:
For more information about security software and features, go to the HP Client Security Software Suite webpage.
|
|
Other standard security features
|
SATA 0 and 1 port disablement (via BIOS)
RAID (optional and does require a second hard drive)
Serial, USB enable/disable (via BIOS)
Power-on password (via BIOS)
Setup password (via BIOS)
Support for chassis padlocks and cable lock devices
Security lock slot (lock sold separately)
|
NOTE:
1Absolute agent is activated when customers activate a purchased subscription. Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. The Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. Data Delete is an optional service provided by Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete service, customers must first sign a Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID tokens from Absolute Software.
2Requires an Internet connection to HP web-enabled printer and HP ePrint account registration. Requires optional broadband module. Broadband use requires separately purchased service contract. Check with service provider for coverage and availability in your area. Separately purchased data plans or usage fees might apply. Print times and connection speeds might vary.
NOTE:
HP Cloud Recovery download tool (Cloud Recovery Client) is available under Software and Drivers section on the support page.
Power
|
Specification
|
Description
|
|
Power supply
|
Adapters
Smart 45 W External AC power adapter
HP Smart 45 W External AC power adapter, 2-prong (Japan only)
HP Smart 65 W External AC power adapter
HP Smart 65 W EM External AC power adapter
45 W USB Type-C adapter
65 W USB Type-C adapter
NOTE:
Availability might vary by country/region.
|
|
Power cord
|
1.8 m (5.91 ft) 3-wire plug
1.0 m (3.28 ft) 3-wire plug
1.0 m (3.28 ft) 2-wire plug (2-prong Japan only)
Duckhead power cord 1.0 m (3.28 ft)
Duckhead power cord 1.8 m (5.91 ft)
|
|
Primary battery
|
HP 3-cell 50 Wh Long Life Li-ion (supports HP Fast Charge with 65 W AC adapter)
NOTE:
Battery is internal and not replaceable by customer.
|
Weight/dimensions
|
Specification
|
Description
|
|
Weight
|
Non-touch
Starting at 1.33 kg (2.93 lb)
Touch
Starting at 1.51 kg (3.33 lb)
NOTE:
Weight varies by configuration and components.
|
|
Dimensions (W x D x H)
|
Non-touch and Touch
31.04 x 22.94 x 1.78 cm (12.22 x 9.03 x 0.7 in)
|
